3-Axis Gantry Type Machine Loading Unloading Manipulator Servo Driven High Precision Automation

Customization:	Available
Application:	Assembly, Machine Tending, Packaging, Painting, Picking and Placing, Welding, Lathe Turning
Control Mode:	Linear Guiderails

Gantry System for CNC Machines Tending

Efficient Auto Picking and Placing Solution

Our Robotic Arm Gantry System is a compact system ideally suited for high-volume, large-scale production, especially for linear machine layouts. We offer TURN-KEY CNC Machine Tending Solutions, ON-SITE COMMISSIONING & FULL SUPPORT. With our technology, your production becomes faster, more efficient, and safer.

Basic Specifications

Degrees of Freedom	3 Axis Gantry System
Drive Mode	Servo Drive
Payload Capacity	5 kg (Customizable up to 800kg)
Functions	Auto Picking/Placing for Turning, Drilling, Grinding
Reposition Accuracy	±0.02mm

Input Voltage	Single Phase 220V
Protocol	Ethernet, Modbus-RTU/TCP, Profinet
Auto Detection	Visual Inspection/Air Leak/Gauging
Certification	CE
Transport Package	Wooden Box

Why Choose Our Gantry Robot?

Floor Space Saving: Compact overhead design.
High Rigidity: Payload capability from 2kg to 800kg.
Easy Operation: No complex programming knowledge required.
Precision: High repeatability of ±0.02mm.
Cost-Effective: 1 operator can manage 4-10 machines.
Low Maintenance: High-quality components with global availability.

Technical Parameters

Performance & Specification
Number of Axis	2 ~ 7 Axis
Motor Type	Servo with Absolute Encoder
Linear Motion	High-precision Guide Rail
Transmission	Rack and Pinion
Payload Range	5kg, 10kg, 20kg, 40kg, 100kg, 200kg, 600kg
Control System	PLC Motion Control
Movement Speed
X-Axis	2000 - 12000mm (Up to 1300mm/s)
Y-Axis	500 - 1500mm (Up to 1000mm/s)
Z-Axis	1000 - 1200mm (Up to 1000mm/s)

Application & Versatility

Our Advantages

OEM/ODM Capabilities for custom requirements.
Safety and Trust in Automated Production lines.
Over 10,000 automation systems delivered worldwide.
Comprehensive turnkey automation solutions.

Related Solutions

6-Axis Tending Robots
Bar Feeders & Conveyors
Gantry Loaders
Truss Manipulators

Professional Automation Solutions

As a leading industrial automation provider, we specialize in CNC tending gantry robots and custom automation systems. Established with deep industry expertise, we have a track record of delivering stable operations and improved productivity for manufacturing facilities globally. Rather than simply providing hardware, we deliver integrated systems designed for long-term efficiency.

Frequently Asked Questions

What components are included in the automated set?

A complete set includes the automated machine tool loading/unloading equipment, industrial robots (3-axis or 6-axis), gantry loaders, bar feeders, and conveyors as per your layout requirements.

What is the typical workflow for international orders?

The process involves: Data gathering → Solution & Quotation → Order Confirmation → Production → Testing → Quality Check → Delivery → Remote or On-site Installation.

How long is the production lead time?

Standard models typically ship within 20–30 days. Specialized or highly customized units require approximately 30–45 days depending on complexity.

Do I need specialized programming skills to operate the robot?

No, the system is designed for ease of use. Operators can handle daily functions without advanced PLC programming skills. We provide simple start-up guidance.

What kind of after-sales support is provided?

We offer free remote technical guidance for the entire life cycle of the equipment. If necessary, technicians can be dispatched for on-site installation and guidance.

Is the system compatible with different CNC brands?

Yes, our gantry systems are designed to be highly versatile and can be integrated with both new and existing CNC machines from various manufacturers.

Product Detail

3-Axis Gantry Type Machine Loading Unloading Manipulator Servo Driven High Precision Automation

Product Description
